Excelon Plus filter/regulator and lubricator combination unit, 1/4 PTF, manual drain, with shut off valve, gauge and brackets
|
| Medium |
Compressed air |
| Operating Temperature |
-20 … 65 °C, -4 … 149 °F |
| Port Size |
1/4 PTF |
| Drain Type |
Automatic |
| Filter Element |
40 μm |
| Adjustment |
Knob |
| Maximum Inlet Pressure |
17 bar, 247 psi |
| Outlet Pressure Adjustment |
0.3 … 10 bar, 4 … 145 psi |
| Relieving/Non-Relieving |
Relieving |
| Valve Operation |
3/2 |
| Lubricator Fog Type |
Micro fog |
| Bowl Capacity |
0.056 l |
| Flow |
22 dm3/s, 46 scfm |
| Start point |
1.2 dm3/sec, 2.5 scfm |
| Materials – Adjusting Knob |
Acetal |
| Materials – Body |
Aluminium alloy |
| Materials – Bonnet |
Acetal |
| Materials – Bowl |
Zinc alloy |
| Materials – Elastomers |
Nitrile rubber (NBR) |
| Materials – Filter Element |
Polypropylene (PP) |
| Dimensions – Height |
240 mm |
| Dimensions – Length |
150 mm |
| Dimensions – Width |
69 mm |
| Weight |
1.3 kg |
| Country of Origin |
Germany |
| Range |
BL82 |
| Series |
Excelon Plus |
| Brand |
IMI Norgren |
